Instrumentation Cable
Cable are generally designed for indoor and outdoor that convey low energy electrical signals used for monitoring or controlling electrical power systems and their associated processes. Typical applications include industrial equipment control, broadcasting, assembling equipment, or mass transit systems.
Specification : SANS 1501-2
Conductor: Copper Conductor Annealed plain or Tinned Stranded round class-2 or Flexible class-5 as per EN 50288-1
Insulation: PVC as per EN 50228-1,EN 50290-2-21
Pairing: Pair colour WHITE/BLUE with pair number printing
Two insulated cores shall be uniformly twisted together to form a pair with a maximum lay length of 100 mm.
Individual:
Screening each pair screened with Aluminium Mylar tape helically applied with the metallic side down, in electrical contact with a tinned annealed copper drain wire 0.5 Sq.mm.
Cabling Overall
Twisted pair are laid up together.
Binder Tape (Optional) Outer sheath: Screening Accumulated pair screened with Aluminium Mylar tape, helically applied with the metallic side down, in electrical contact with a tinned annealed copper drain wire of
0.5 Sq.mm.Polyester (Mylar) Tape PVC (Polyvinyl Chloride) as per EN 50288- 1,EN 20290-2-22, (Special Requirement Low Halogen Flame Retardant & Zero Halogen Flame Retardant as per EN 50290-2-26)
Temperature rating fixed: -15°C to + 90°C
Sheath Colour: Blue, Black & as per Requirement
